Type

Rated

voltage

(KV)

Specifified mechanical

 load    (kN)

Section

length

(mm)

Min Arc

distance

(mm)

Leakage distance (mm)

Lightning

impulse

withstand

BIL(KV)

Power

frequency

withstand

(wet) (KV)

FXBW-110/70

110

70

1240

1000

3450

550

230

FXBW-110/100

110

100

1250

1000

3450

550

230

FXBW-110/160

110

160

1240

980

3200

550

230

FXBW-115/120

115

120

1240

1000

3450

550

230

FXBW-115/160

115

160

1340

1000

3300

550

230

FXBW-132/70

132

70

1340

1140

3630

650

275

FXBW-132/120

132

120

1500

1300

4110

650

275

FXBW-132/160

132

160

1500

1280

3900

650

275

FXBW-138/70

138

70

1500

1300

4000

650

275

FXBW-138/120

138

120

1622

1470

4692

650

275

FXBW-138/160

138

160

1652

1440

4500

650

275

We can customize products according to
the parameters and drawings required by customers
